OpenGL: 基本幾何圖形之一

since: 2012/04/27
update: 2012/04/28
reference:
OpenGL: A Primer, 3/e

基本幾何圖形之一: 點

A. 說明:
     1. 延續之前文章: I touchs: OpenGL: General Strucure 的專案.

     2. 將繪圖函式額外獨立成 .h 與 .cpp 檔案.

------------------------------------------------------------------------------

B. 新增給繪圖函式使用的檔案:
     1. Xcode > File > New > File...
         > Mac OS X > C and C++ > Header File > Next

              Save As: draw.h

              Targets: OpenGLStart checked
              > Create

     2. Xcode > File > New > File...
         > Mac OS X > C and C++ > C++ File > Next

              Save As: draw.cpp

              Targets: OpenGLStart checked
              > Create

     3. 開啓 draw.h 檔案, 修改如下:
//@update
/*
#ifndef OpenGLStart_draw_h
#define OpenGLStart_draw_h

#endif
*/

     4. 開啓 draw.cpp 檔案, 修改如下:
//#include <iostream>
//@add
#include <OpenGL/OpenGL.h>
#include <GLUT/GLUT.h>

     5. 開啓 main.cpp 檔案, 修改如下:
#include <OpenGL/OpenGL.h>
#include <GLUT/GLUT.h>
#include "draw.h"
....

------------------------------------------------------------------------------

C. 畫點

     1. 開啓 draw.h 檔案, 修改如下:
//@add: drawing
void drawPoints(); // 畫點

     2. 開啓 draw.cpp 檔案, 修改如下:
....
//@add: drawing
//
// 畫點
void drawPoints()
{
    // Clear the buffer
    glClear(GL_COLOR_BUFFER_BIT);

    //@add: Set the color for this polygon (Red)
    //
    //state: current drawing color
    //glColor3f(1.0, 0.0, 0.0);

    //@add: sets the point size state variable
    //
    // default: 1.0
    // p.s. glPointSize() 只能在 glBegin() 與 glEnd() 區間之外設定.
    glPointSize(10.0);

    // Let us begin drawing some points
    //glBegin(GL_POLYGON);
    glBegin(GL_POINTS);

    // Specify the points
    glColor3f(1.0, 1.0, 1.0); // Set the color state: white
    glVertex2f(-0.5, -0.5);

    glColor3f(1.0, 0.0, 0.0); // Set the color state: red
    glVertex2f(-0.5, 0.5);

    glColor3f(0.0, 1.0, 0.0); // Set the color state: green
    glVertex2f(0.5, 0.5);

    glColor3f(0.0, 0.0, 1.0); // Set the color state: blue
    glVertex2f(0.5, -0.5);

    // Ok we are done specifying points
    glEnd();

    // Write this out to the screen
    glFlush();
}

     3. 開啓 main.cpp 檔案, 修改如下:
....
int main(int argc, char * argv[])
{
....
    // Set the callback function, will be called as needed
    //glutDisplayFunc(display);
    glutDisplayFunc(drawPoints); // 畫點
....
}

     4. 編譯並執行:

OpenGL: General Strucure

since: 2012/04/27
update: 2012/04/28
reference:
1. OpenGL: A Primer, 3/e
2. 投影的分類(Classification) - 3D2D projection

A. 說明:
     延續 I touchs: Beginning OpenGL on Mac OS X 這篇文章的專案, 來調整成
     OpenGL 常用的程式結構.

-------------------------------------------------------------------------------------

B. 開啓 main.cpp 檔案, 修改如下:
....
//@add: Let us create a function to initialize everything
void init()
{
    // This determines the background color, in this case: gray
    // state: current clear color
    glClearColor(0.5, 0.5, 0.5, 1.0); // R, G, B, A

    // Determines which matrix to apply operations to.
    // value: GL_PROJECTION or GL_MODELVIEW
    glMatrixMode(GL_PROJECTION); // default vlew

    // Loads the Identity matrix
    glLoadIdentity();

    // 正投影(Orthographic Projection)
    //
    // The gluOrtho2D function defines a 2-D orthographic projection matrix.
    //
    // Set the size and projection of the buffer
    // (x left, x right, y bottom, y top)
    // corner => (left, bottom), (right, top)    gluOrtho2D(-1.0, 1.0, -1.0, 1.0); // default
}

void display()
{
    // Clear the buffer
    glClear(GL_COLOR_BUFFER_BIT);

    //@add: Set the color for this polygon (Red)
    //
    //state: current drawing color
    glColor3f(1.0, 0.0, 0.0);

    // Let us begin drawing some points
    glBegin(GL_POLYGON);

    // Specify the points
    glVertex2f(-0.5, -0.5);
    glVertex2f(-0.5, 0.5);
    glVertex2f(0.5, 0.5);
    glVertex2f(0.5, -0.5);

    // Ok we are done specifying points
    glEnd();

    // Write this out to the screen
    glFlush();
}

int main(int argc, char * argv[])
{
    // insert code here...
    //std::cout << "Hello, World!\n";

    //@add for OpenGL
    //
    // Init glut
    glutInit(&argc, argv);

    //@add: Specify the Display Mode
    //
    // this one means there is a single buffer
    // and uses RGB to specify colors (default)
    glutInitDisplayMode(GLUT_RGB|GLUT_SINGLE);

    //@add: Set the window size
    glutInitWindowSize(640, 480);

    //@add: Where do we want to place the window initially?
    glutInitWindowPosition(100,100);

    // Name the window and create it:
    //
    // default position: upper-left corner
    // default size: 300 x 300 pixels
    glutCreateWindow("Hello OpenGL");

    // Set the callback function, will be called as needed
    glutDisplayFunc(display);

    //@add: Initialize the window
    init();

    // Start the main loop running, nothing after this
    // will execute for all eternity (right now)
    glutMainLoop();

    //@update: will not be executed
    //return 0;
}

-------------------------------------------------------------------------------------

C. 編譯並執行:

Beginning OpenGL on Mac OS X

since: 2012/04/23
update: 2012/04/27

reference:
1. Beginning OpenGL on OS X
2. OpenGL: A Primer, 3/e

A. 說明:
      在繼續學習 OpenGL ES 前, 想先對 OpenGL 多瞭解一些, 這裡的學習記錄,
      可能會多次的更新與修正, 僅供參考.

------------------------------------------------------------------------------------------

B. 環境:
     1. MacBook Pro (13-inch, Mid 2009)
     2. Mac OS X 10.7.3
     3. Xcode 4.3.2
     4. 檢測目前的環境:
          OpenGL Extensions Viewer

     說明: 可以看到目前這台電腦支援的 OpenGL 版本為:
               完全支援: 1.1 ~ 2.1
               部分支援: 3.0 ~ 3.3
               全不支援: 4.0 ~ 4.2

------------------------------------------------------------------------------------------

C. 新增專案:
     1. Xcode > File > New > Project... > Mac OS X > Application >
         Command Line Tool > Next

       Product Name: OpenGLStart

       Company Identifier: com.blogspot
       Type: C++
       Use Automatic Reference Counting: checked
       > Next > Create

     2. 新增 Framework:

       OpenGL
        - OpenGL is the premier environment for developing portable,
           interactive 2D and 3D graphics applications.

       GLUT

        - OpenGL Utility Toolkit

------------------------------------------------------------------------------------------

D. 開啓 main.cpp 檔案, 修改如下:
//This is just for basic io, you really DON'T need it
//#include <iostream>

//@add
#include <OpenGL/OpenGL.h> // OpenGL Library
#include <GLUT/GLUT.h> // GLUT Library, will make you life easier

//@add
void display()
{
    // Clear the buffer
    glClear(GL_COLOR_BUFFER_BIT);

    // Let us begin drawing some points
    glBegin(GL_POLYGON);

    // Specify the points
    glVertex2f(-0.5, -0.5);
    glVertex2f(-0.5, 0.5);
    glVertex2f(0.5, 0.5);
    glVertex2f(0.5, -0.5);

    // Ok we are done specifying points
    glEnd();

    // Write this out to the screen
    glFlush();
}

//int main(int argc, const char * argv[])
//@update: just remove "const"
int main(int argc, char * argv[])
{
    // insert code here...
    //std::cout << "Hello, World!\n";

    //@add for OpenGL
    //
    // Init glut
    glutInit(&argc, argv);

    // Name the window and create it
    //
    // default position: upper-left corner
    // default size: 300 x 300 pixels
    glutCreateWindow("Hello OpenGL");

    // Set the callback function, will be called as needed
    glutDisplayFunc(display);

    // Start the main loop running,
    // nothing after this will execute for all eternity (right now)
    glutMainLoop();

    //@ will not be executed (update: 2012/04/26)
    //return 0;
}

------------------------------------------------------------------------------------------

E. 編譯並執行:

------------------------------------------------------------------------------------------

F. 備註:
     1. MeshLab 軟體.
         可用來讀取與編輯鬆散的 3D 三角形面的網狀模型.
         (unstructured 3D triangular meshes)
         p.s. 可以從 The Stanford 3D Scanning Repository 下載 3D 模型檔.

      (bunny\reconstruction\bun_zipper.ply)
      看看可愛的 Bunny ~

------------------------------------------------------------------------------------------

     2. Nate Robins - OpenGL - Tutors
         a. 下載:
              Tutors source code package (tutors-src.zip 920KB)

         b. 解壓縮後, 開啓 tutors.xcodeproj
              將右上方的 "active scheme" 選為 shapes 或 lightmaterial, 然後執行.

         c. 執行結果
             shapes:

             lightmaterial:
